Fukushima Futaba CWR5 68R J Resistance wire 68 Ω Radial lead 5 W 5 % 1 pc(s) Bulk
Part number:
Item no:
Packaging type
Bulk
Product type
Resistance wire
Resistance
68 Ω
Power rating
5 W
Content
1 pc(s)
Datasheet (PDF)
Highlights & Details
Fukushima Futaba wire resistor 5W 5% 68R
Our service for you
Technical specifications
- Series CWR
- Delivery form: Loose
- Diameter, connection wire 0.8 mm
- Solder-ability 350 °C / 3 s.
- Resistance tolerance: ±5 %
- Rated output: 5 W
- Packaging type
Bulk
- Product type
Resistance wire
- Type
Radial lead
- Resistance
68 Ω
- Power rating
5 W
- Tolerance ±
5 %
- Temperature coefficient
350 ppm/°C
- Length
13.0 mm
- Width
9.0 mm
- Height
25.5 mm
- (Ø)
0.8 mm
- CS
5 mm
- Max. temperature
+155 °C
- Min. temperature
-25 °C
- Insulation resistance
10 MΩ
- Content
1 pc(s)
- Dim
(Ø x H) 0.8 mm x 25.5 mm
- RoHS-compliant
Yes
- Type
CWR5 68R J
- Mounting type
PCB mount
- Operating temperature (max.)
155 °C
- Operating temperature (min.)
-25 °C
- Certification marks
JIS C5202
Documents & Downloads
Datasheet
Datasheet 3463678 Fukushima Futaba CWR5 68R J Resistance wire 68 Ω Radial lead 5 W 5 % 1 pc(s) Bulk
User & Safety Instructions
User & Safety Instructions 3463678 Fukushima Futaba CWR5 68R J Resistance wire 68 Ω Radial lead 5 W 5 % 1 pc(s) Bulk
Description
Metal strip and performance resistors
This text is machine translated.
This text is machine translated.
Features
- Metal strap-Resistance
- Miniature power resistor
- Special ceramic allows for miniature design
- Special alloys for low ohm values and TK
- High-vacuum coating for long-term stability
- Completely non-flammable
- With a wire element
