Gedore 6057430 400 12X14 Double-ended box wrench Spanner size (metric) 12 - 14 mm
EAN:
Part number:
Item no:
Number
Total (€ 21.00 / piece)
€ 21.00
plus VAT.
14-day return policy included
Technical specifications
- DIN3118
- Size 8 x 10 to 12 x 14 mm with 6-edged ring
- GEDORE Vanadium Steel 31 CrV3, chrome-plated
- Application to the hydraulic/Brake Lines
- Application:
- Heads are angled at 15°
- 6-edged opening 30° apart, UD-profile opening 15° offset
- Product type
Double-ended box wrench
- Spanner size
12 mm
14 mm
- Size
12
- Length
170 mm
- Material
Chromium-vanadium steel
- Material properties
chrome plated
- DIN standard
DIN 3118
- Height
15 mm
- Width
26 mm
- Weight
92 kg
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1906172 Gedore 6057430 400 12X14 Double-ended box wrench Spanner size (metric) 12 - 14 mm
Information
Information 1906172 Gedore 6057430 400 12X14 Double-ended box wrench Spanner size (metric) 12 - 14 mm
Description
Features
- Acc. to DIN 3118
- Ring 15° offset from shaft
- Hexagon gap 30° offset, UD-section at 15° offset
- Sizes 8x10 to 12x14 mm with hexagon
- For applications involving hydraulic/brake lines
- GEDORE vanadium steel 31CrV3, chrome-plated
