Gedore 763-10 1948016 Torque wrench 1/4" (6.3 mm) 10 - 10 Nm
EAN:
Part number:
Item no:
Number
Total (€ 151.25 / piece)
€ 151.25
plus VAT.
14-day return policy included
Technical specifications
- 763-10 - GEDORE - Torque wrench DREMOMETER T-FS 1/4" fixed set 10Nm
- Application:
- Force-protecting application for torques that are usually in the range of torque screwdrivers
- , for example Module mounting in solar plants, tool holders etc., wherever the torques for classic torque screwdrivers are too large
- Design:
- Torque wrench series with 8 preset models for series production
- for the controlled right-handed suit
- Trip accuracy according to DIN EN ISO 6789:2003 Type II Class E (+/- 6 %)
- Light and robust - housing made of high-quality aluminum alloy
- with certificate according to DIN EN ISO 6789:2003, traceable via company-owned DAkkS laboratory to the National Standard
- special areas on request
- Product type
Torque wrench
- Downforce
1/4" (6.3 mm)
- Torque (min.)
10 Nm
- Torque (max.)
10 Nm
- Trigger accuracy
6 %
- Length
100 mm
- Weight
545 g
- Width
125 mm
- Height
22 mm
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1908300 Gedore 763-10 1948016 Torque wrench 1/4" (6.3 mm) 10 - 10 Nm
Information
Information 1908300 Gedore 763-10 1948016 Torque wrench 1/4" (6.3 mm) 10 - 10 Nm
Description
Features
- Use:
- Power-saving application for torques which are usually in the range of torque screwdrivers
- E.g. securing modules on solar power systems, tool supports etc.; wherever the torques are too large for classic torque screwdrivers Features:
- Torque wrench series with 8 pre-set models for serial production
- For controlled clockwise tightening
- Working accuracy in accordance with DIN EN ISO 6789:2017 Type II Class E (+/- 6 %)
- Lightweight and robust - housing made of a high-quality aluminium alloy
- With certificate acc. to DIN EN ISO 6789:2017, traceable via in-house DAkkS laboratory to national standards
- Special ranges are available on request
