Gesipa 1433925 Blind rivet (Ø) 4.8 mm Steel Steel Steel 500 pc(s)
EAN:
Part number:
Item no:
Product type
Blind rivet
Material (spike)
Steel
Material (sleeve)
Steel
Material
Steel
Max. clamping range
3.5 mm
Number (Package size 500 pc(s))
Total (€ 0.12 / piece)
€ 60.50
plus VAT.
14-day return policy included
Technical specifications
- Product type
Blind rivet
- (Ø)
4.8 mm
- Content
500 pc(s)
- Material (spike)
Steel
- Material (sleeve)
Steel
- Dim
(Ø) 4.8 mm
- Material
Steel
- Max. clamping range
3.5 mm
- Min. clamping range
1.5 mm
- Tubular rivet diameter
4.8 mm
- Tubular rivet length
10 mm
- Clamping range
1.5 - 3.5 mm
- Head Ø
9.5
- Head height
1.6 mm
- Material properties
zinc plated
- Material properties (spikes)
zinc plated
- Material properties (sleeves)
zinc plated
- Rivet mandrel diameter
3.2 mm
- Shear force
3600 N
- Head shape
Truss head
- Tensile force (max.)
3500 N
