Gesipa 1818484 Blind rivet Steel (galvanized) Aluminium alloy Steel 250 pc(s)
EAN:
Part number:
Item no:
Product type
Blind rivet
Material (spike)
Steel (galvanized)
Material (sleeve)
Aluminium alloy
Material
Steel
Max. clamping range
6.50 mm
Datasheet (PDF)
Quantity (Set(s))
Savings
Package size (plus VAT.)
1
-
€ 21.00
3
4% = € 0.92
€ 20.08
Volume discounts vary depending on the seller
You save € 0.00
Number (Package size 250 pc(s))
Total (€ 0.08 / piece)
€ 21.00
plus VAT.
14-day return policy included
Highlights & Details
Universal grip blind rivets aluminum/steel 4.0 x 10
- Long rivet pin - enables the use of extended mouthpieces
- Economical – one dimension can replace up to five standard dimensions
- Easy to use - with standard device and extended standard mouthpiece
- Standardization – even for small annual requirements
Technical specifications
- Product type
Blind rivet
- Content
250 pc(s)
- Material (spike)
Steel (galvanized)
- Material (sleeve)
Aluminium alloy
- Material
Steel
- Max. clamping range
6.50 mm
- Min. clamping range
0.50 mm
- Tubular rivet diameter
4.00 mm
- Tubular rivet length
10.00 mm
- Clamping range
0.50 - 6.50 mm
- Head Ø
8.00
- Hole diameter
4.10 mm
- Material properties (sleeves)
zinc plated
- Rivet mandrel diameter
2.30 mm
- Shear force
1.060 N
- Head shape
Truss head
- Tensile force (max.)
1.680 N
Documents & Downloads
Datasheet
Datasheet 3411694 Gesipa 1818484 Blind rivet Steel (galvanized) Aluminium alloy Steel 250 pc(s)
User & Safety Instructions
User & Safety Instructions 3411694 Gesipa 1818484 Blind rivet Steel (galvanized) Aluminium alloy Steel 250 pc(s)
Description
GESIPA Universal Grip - The PolyGrip connector for difficult to access rivet joints
For applications where there is very little space for the processing device due to the design (interference edges, deep depressions), the use of extended mouthpieces is recommended. However, you need a blind rivet with extended rivet pin. The Universal Grip blind rivet is now available for these applications. The Universal Grip combines the advantages of PolyGrip with those of an extended rivet punch and can be processed with all our mouthpieces with special length.
Area of application
• Hard-to-reach rivet areas of any kind, e.g. riveting in profiles
• Rivets close to component edges
THE ADVANTAGES OF UNIVERSAL GRIP
• Long rivet punch - allows the use of extended mouthpieces
• Large clamping area - one dimension can replace up to five standard dimensions
• Economical - usable with standard device and extended standard mouthpiece
• Standardization - also for small annual requirements
This text is machine translated.
For applications where there is very little space for the processing device due to the design (interference edges, deep depressions), the use of extended mouthpieces is recommended. However, you need a blind rivet with extended rivet pin. The Universal Grip blind rivet is now available for these applications. The Universal Grip combines the advantages of PolyGrip with those of an extended rivet punch and can be processed with all our mouthpieces with special length.
Area of application
• Hard-to-reach rivet areas of any kind, e.g. riveting in profiles
• Rivets close to component edges
THE ADVANTAGES OF UNIVERSAL GRIP
• Long rivet punch - allows the use of extended mouthpieces
• Large clamping area - one dimension can replace up to five standard dimensions
• Economical - usable with standard device and extended standard mouthpiece
• Standardization - also for small annual requirements
This text is machine translated.
