Name: Gigabyte Gigabyte B840M D3HP Motherboard PC base #####AMD AM5 Form factor (details) Micro-ATX Motherboard chipset AMD® B
Brand: Gigabyte
SKU: 3620084

A Gigabyte B560M D3H motherboard featuring multiple USB ports, audio jacks, RAM slots, and PCIe slots, designed for computer assembly.

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Motherboard

Chipset: AMD® B840

: #####AMD AM5

Form factor: Micro-ATX

Processor/type: Ryzen 9000 / 8000 / 7000 Serienprozessoren

RAM type: DIMM

RAM / Max. upgrade: 256 GB

Interfaces: HDMI® 2.1

No. of DDR5 slots: 4 x

No. of LAN ports: 1 x

No. of Gigabit LANs: 1 x

No. of PCIe 3.0 x16: 1 x

No. of USB 2.0 ports: 1 x

No. of SATA III ports: 4 x

Onboard audio: 7.1

Depth: 244 mm

Height: 35 mm

Width: 244 mm

Display resolution: 4096 x 2160 Pixel

No. of DisplayPort: 2 x

No. of HDMI ports: 1 x

No. of USB A 2.0 ports: 3 x

No. of USB type A 3.1 / 3.2 1st Gen: 1 x

No of. USB type A 3.1 /3.2 2nd gen: 1 x

Christmas lighting features: 12.0

Cooling: Passive

HDCP: Yes

Battery capacity: 220 mAh

10/100/1000 Mbps ports: 1 x

Range of use: PC

Weight: 960 g

Wi-Fi: No

UKCA: yes

BIOS memory size: 256 Mbit

Screws included: yes

Line-in: yes

Ethernet LAN: yes

PCI Express x1 (Gen 3.x) slots: 1

Number of memory slots: 4

Number of M.2 (M) slots: 2

Products per shipping (inner) case: 1 Stück(e)

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1

Headphone outputs: 1

Microphone in: yes

Front panel connector: yes

CPU fan connector: yes

ATX Power connector (24-pin): yes

Front panel audio connector: yes

Number of HDDs supported: 4

TPM connector: yes

RGB LED pin header: yes

Supported memory clock speed (max): 8200 MHz

Lithium weight per battery: 0.07 g

Battery weight: 3 g

Batteries included: yes

EPS power connector (8-pin): yes

RAID support: yes

Package weight: 1.04 kg

USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2

Unbuffered memory: yes

Clear CMOS jumper: yes

Number of storage drives supported: 6
