Image similar
Image similar
Glen Dimplex UPE 80-25PK Circulation pump 3.5 m³/h 10 bar
EAN:
Part number:
Item no:
Technical specifications
- Protection type (IP): IPX4D
- Number of phases: 1
- Nominal current: 0.66 A
- Rated voltage 220..240 V
- Mains frequency: 50/60 Hz.
- Potential-free switch contact: No.
- Cable length: 1.5 m
- Ambient temperature -20..70°C
- Wireless standard 5G: No
- Supports protocol for PROFIBUS: No.
- Supports protocol for KNX: No.
- Supports protocol for PROFINET IO: No.
- Supports protocol for Ethernet/IP: No.
- Wireless standard Bluetooth: No.
- Wireless standard WLAN 802.11: No.
- Mounting length 180 mm
- Electrical connection: Connection cable with plug
- Medium temperature (continuous operation): -20..110°C
- Max. Operating pressure 10 bar
- Pump housing material: Cast iron
- Material of blower wheel/impeller: Polypropylene (PP)
- Material quality Blower wheel/impeller: PP-GF
- Pump circuit: Other
- Interface signal 0-20 mA / 4-20 mA: No.
- Interface PT100 / PT1000 / PTC: No.
- Pulse counter interface: No.
- Supports protocol for CAN/CANopen: No.
- Supports protocol for Modbus TCP: No.
- Supports protocol for Modbus RTU: No.
- Supports protocol for BACnet MS/TP: No.
- Supports protocol for BACnet IP: No.
- Supports protocol for LON/LonWorks: No.
- Supports protocol for LIN Bus: No.
- Inlet side connection: Male thread (metric)
- Outlet side connection: External thread (metric)
- Type of speed control: Infinitely variable
- Volume flow (BEP): 3.5 m³/h.
- Volume flow delivery height (BEP): 80 kPa
- Max. pumping height 8.5 m
- Double pump: No.
- Engine power absorbed (P1): 75 kW
- Energy efficiency class (EEI): 0.21
- Insulation class IEC F
- Motor speed control: Integrated
- Communication: Integrated and prepared
- Wireless standard 2G: No
- Interface signal 0-10 V / 2-10 V: No.
- 3G wireless standard: No.
- 4G wireless standard: No.
- Pulse Width Modulation (PWM) interface: Yes
- With RS-485 communication interface: No.
- With RS-232 communication interface: No.
- Diameter, inlet side connection: 1 1/2 in. (40)
- Nominal diameter, outlet side connector: 1 1/2 in. (40)
- Product type
Circulation pump
- Operating voltage
230 V AC
- Hose connector
DN 40
- Pressure connection
DN 40
- Max. operating pressure
10 bar
- Max. feed rate
3.5 m³/h
- Max. delivery head
8.5 m
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3552350 Glen Dimplex UPE 80-25PK Circulation pump 3.5 m³/h 10 bar
Description
High-efficiency wet runner pump for use in heat pump systems, especially in the consumer circuit (heating and cooling) as well as in the solar circuit through cataphoresis coating and firmly stored speed levels. Control types for optimum load adjustment selectable via control button: Fixed speed levels (I, II.
III) and differential pressure control constant (?p-c) 3-stage, optional control by means of external input signal possible (signal cable not included in delivery). Bleeding function available. Delivery height max. 8.4 m at a throughput of 1.1 m3/h, volume flow max. 3.5 m3/h with a delivery head of 2.2 m
Max. Pressure stage PN 10
Energy efficiency EEI ? 0.21. Pitch 180 mm
Power supply 1/N/PE ~ 230 V, 50 Hz. Dimensions: H x D x W 180 x 138 x 94 mm. Connection cable load 1.5 m and seals (2x) included with delivery.
