Gooseneck Speech microphone JTS CS-1CU Transfer type (details):Corded
EAN:
Part number:
Item no:
Technical specifications
- Connections: 2 x cinch (Input/output for telephone coupler)2 x cinch (Input/output for e.g. equalizer)2 x cinch L/R (Input/output for recording device)2 x cinch (Input/output for line signals)1 x XLR (microphone input)2 x 7-pin DIN socket (connection for speech units)
- Power supply 100-240 VAC/50-60 Hz/90 VA
- Dimensions 360x90x150 mm
- Weight: 1.7 kg
- Product type
Speech microphone
- Type
Gooseneck
- Transfer type
Corded
- Weight
1.7 kg
- Width
360 mm
- Height
90 mm
- Dim
(W x H x D) 360 x 90 x 150 mm
- Interfaces
RCA (phono)
XLR
- Depth
150 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1331455 Gooseneck Speech microphone JTS CS-1CU Transfer type (details):Corded
Description
Features
- Conference system CS-1 Your opinion is heard! The CS-1CU control unit, the CS-1CH conference line call station and the CS-1DU conference call station together form a conference system with extensive configuration options for maximum flexibility. Controller Is The control center of the conference system. The CS-1CU enables the setup of a system with up to 50 call stations and simultaneously takes over their operating voltage supply. Through adjustable discussion modes (e.g. Number of simultaneous speakers, talk time limit, exclusive release for conference line . . . ) it is possible to optimally adapt the system to the corresponding requirements. A built-in speaker or optional headphones allow you to follow the discussion directly at the control unit. Other features: Key lock, date/time display, stopwatch, test function for connected call stations. Connection options for optional devices such as external microphone, telephone coupler, signal processing devices (e.g. Equalizer), recording devices, amplifiers, audio line sources. Suitable call stations CS-1DU and CS-1CH. AV-views 02/2010 A conference system, solid and reliable. The speech intelligibility of the system is good.
- This text is machine translated.
