Gossen Metrawatt METRAHIT AM TECH Handheld multimeter Calibrated to (DAkkS standards) Digital CAT III 1000 V, CAT IV 600
EAN:
Part number:
Item no:
Datasheet (PDF)
Total (€ 621.01 / piece)
€ 621.01
plus VAT.
14-day return policy included
Highlights & Details
Digital-MultiMate METRAHIT TECH
- AC voltage measurement in addition, "low resistance" (1 MΩ)
- Switch able-1 kHz/-3 dB low pass filter
- TrueRMS-Bandwidth 10 kHz
- Direct Current measurement 1 µA - 10 A (16 A)
- Current clamp sensor connectable
Technical specifications
- Voltage reading range DC (min.)
0.01 mV
- Product type
Handheld multimeter
- Voltage DC reading range (max.)
1000 V
- V AC reading range (min.)
0.01 mV
- V AC reading range (max.)
1000 V
- Amperage reading range DC (min.)
0.001 mA
- A DC reading range (max.)
10 A
- A AC reading range (min.)
0.001 mA
- Amperage reading range AC (max.)
10 A
- Reading range - resistance
10 mΩ - 40 MΩ
- Reading range - capacity
10 pF - 1000 µF
- Frequency reading range
0.01 Hz - 100 kHz
- Temperature
-50 to +1372 °C
- DC resistance
9 MΩ
- AC resistance
9 MΩ
- Basic accuracy
0.05 %
- Measurement type (details)
True RMS
- Frequency range
15 Hz - 10 kHz Hz
- Interfaces
none
- Power supply (details)
2 AA batteries
- Height
200 mm
- Width
87 mm
- Weight
350 g
DAkkS standards
- Reading category
CAT III 1000 V
CAT IV 600 V
- Voltage metering
AC/DC
- Current reading
AC/DC
- Type
METRAHIT AM TECH
- Display
Digital
- Display (counts)
12000
- Dim
(W x H) 87 mm x 200 mm
- Temperature reading range (max.)
+1372 °C
- Temperature reading range (min.)
-50 °C
- Basic accuracy
± 3% + 5 digits
- Displays
12000 counts
Documents & Downloads
Datasheet
Datasheet 122267 Gossen Metrawatt METRAHIT AM TECH Handheld multimeter Calibrated to (DAkkS standards) Digital CAT III 1000 V, CAT IV 600
User & Safety Instructions
User & Safety Instructions 122267 Gossen Metrawatt METRAHIT AM TECH Handheld multimeter Calibrated to (DAkkS standards) Digital CAT III 1000 V, CAT IV 600
Conformity certificate
Conformity certificate 122267 Gossen Metrawatt METRAHIT AM TECH Handheld multimeter Calibrated to (DAkkS standards) Digital CAT III 1000 V, CAT IV 600
Description
The new multimeters in the STARLINE generation are robust, reliable digital multimeters with housing made of impact-resistant plastic. The devices are distinguished by their exemplary technique as 3 sockets with automatic blocking sockets (ABS), TRMS measurement to 20 kHz and temperature measurement using K-type thermocouple (Pt100/Pt1000 addition to X-tra), and an illuminated display with large digits from.
Features
- 3 sockets with automatic socket lock
- Large lit display, digit height 15 mm
- Separated battery, and fuse compartments
- Protection class IP52
- DKD calibration certificate.
Scope of delivery
- Set safety test leads
- 2 batteries 1.5 V, AA
- Manual
- DKD calibration certificate.
Hints
AC voltage measurement in addition, "low" (1 MW)
Switchable -1 kHz/-3 dB low pass filter
Measures direct/indirect current
