Green Cell Non-standard battery (rechargeable) LiFePo PP3 Blade terminal LiFePO4 12.8 V 7 Ah
EAN:
Part number:
Item no:
Datasheet (PDF)
Green Cell LiFePO4 battery block
Highlights & Details
- Minimal self-dischargeLong operating lifeLightweightWith BMS battery management system
Technical specifications
- Size
LiFePo PP3
- Product type
Non-standard battery (rechargeable)
- Technology
LiFePO4
- Dim
(W x H x D) 65 x 95 x 151 mm
- Voltage
12.8 V
- Capacity (mAh, Ah)
7 Ah
- Special-purpose battery features
Blade terminal
- Max. charge voltage
14.6 V
- Max. charging current
5 A
- Terminal voltage
9.2 V
- Discharge current (max.)
15 A
- Continuous discharge
7 A
- Min. temperature
-10 °C
- Max. temperature
+55 °C
- Width
65 mm
- Height
95 mm
- Depth
151 mm
- Weight
940 g
- Content
1 pc(s)
- Type
CAV09
- Rechargeable
Yes
- Integrated surge protection
Yes
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2543099 Green Cell Non-standard battery (rechargeable) LiFePo PP3 Blade terminal LiFePO4 12.8 V 7 Ah
Information
Test Summary Report 2543099 Green Cell Non-standard battery (rechargeable) LiFePo PP3 Blade terminal LiFePO4 12.8 V 7 Ah
Security datasheet
Security datasheet 2543099 Green Cell Non-standard battery (rechargeable) LiFePo PP3 Blade terminal LiFePO4 12.8 V 7 Ah
Description
The lithium iron phosphate battery is characterized by extraordinary durability, power efficiency and charging speed. It is also a more important and lighter alternative to lead-acid batteries. Even after 2000 charging cycles, LiFePO4 retain its capacity to over 80% and thus an operating time of over 7 years. Thanks to the low self-discharge, the rechargeable battery is fully operational even after a year of non-use. High durability and durability, low weight and power parameters ensure that the batteries are used for the power supply of recreational vehicles and mobile vehicles, boats and photovoltaics. In addition, the battery is equipped with a BMS battery management system, which not only controls the charging and discharging of the battery, but also the temperature, in order to ensure maximum safety.
