Greisinger GMH 3750-GE Thermometer Calibrated to (SCS-accredited certification body) -199.99 - +850 °C Sensor type Pt100
EAN:
Part number:
Item no:
Highlights & Details
Pt100 digital precision thermometer with logger function GMH 3750-GE
- For all Pt100 4-conductor sensors with 4-pin mini DIN connectors
- 2 integrated logger functions
- User-specific characteristic curve
- Highest accuracy and resolution
- Zero/gradient input
Technical specifications
- Min/max value memory
- Product type
Thermometer
- Max. temperature
+850 °C
- Accuracy ± °C
0.03 °C
- Sensor type
Pt100
SCS-accredited certification body
- Dim
(L x W x H) 26 x 71 x 142 mm
- Resolution (temperature)
0.01 °C
- Weight
155 g
- Width
71 mm
- Height
142 mm
- Length
26 mm
- Power supply
9 V battery (1x)
- Min. temperature
-199.99 °C
- Type
GMH 3750-GE
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2470570 Greisinger GMH 3750-GE Thermometer Calibrated to (SCS-accredited certification body) -199.99 - +850 °C Sensor type Pt100
Description
Excellent accuracy of 0.03 °C and excellent temperature stability characterize this high-quality reference device for Pt100 sensors. For calibration laboratories, quality assurance and routine production operations. Together with the right sensor you get a measuring system with 0.01 °C-display, which fulfills all the requirements playfully and also offers an almost unbeatable price/performance ratio. The device also logs the temperature on request.
This text is machine translated.
This text is machine translated.
Features
- Manual offset and rise correction
- With logger function (approx. 16,000 measured values)
- Analogue output. 0 - 1 V freely scalable
- 2 measurement variables can be selected: °C, °F.
- Min./max. value memory
- Serial interface
- Tare function
- Switches off automatically
Scope of delivery
- Battery
- User manual
Hints
Sensor not included in delivery.
