Greisinger GTH2448/3 LED Display Digital Thermometer -60 to +199.9 °C
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 72.26 / piece)
€ 72.26
plus VAT.
Only 6 Piece(s) available
Highlights & Details
Greisinger switch panel mounted thermometer 24 x 48 mm GTH2448/3
- Supply voltage ranges can be set via solder bridges
- Low installation depth
- Zero-point balancing through spindle trimmer
Technical specifications
- Type
GTH2448/3
- Dim
(W x H x D) 48 x 24 x 65 mm
- Width
48 mm
- Height
24 mm
- Digit height
10 mm
- Depth
65 mm
- Type
Pt100
- Digits
4
- Assembly dimensions
45 x 22 mm
- Accuracy
±0.5 %
- Temperature
-60 to +199.9 °C
- Sample rate
0.3 s
- Temperature resolution
1 °C
- Operating voltage
8 - 29 V/DC/8 - 27 V AC
Documents & Downloads
Datasheet
Datasheet 121548 Greisinger GTH2448/3 LED Display Digital Thermometer -60 to +199.9 °C
User & Safety Instructions
User & Safety Instructions 121548 Greisinger GTH2448/3 LED Display Digital Thermometer -60 to +199.9 °C
Description
Affordable 3 1/2-digit low cost LED display from -60.0 to +199.9 °C, for use with Pt100 temperature sensors. Due to their small size and mounting depth makes this display ideal for use in switchboards, motor vehicles, car racing, etc. Installation with spring clips, connection with screw or plug terminal.
Hints
Sensor not included
