Grothe 39343 Power supply unit Content 1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
Grothe power supply unit NG AL24 1A
- Power supply unit with changeable primary fuseSurface-mounted, DIN rail mounting2 subunits
Technical specifications
- Input voltage 100 - 240 V AC, 50 HzOutput 24 V/DC max. 1 A
- Nominal input voltage
100 - 240 V/AC
- Type
Series installation power supply
- Product type
Power supply unit
- Input voltage (max.)
240 V
- Max. output current
1 A
- Output current (max.) - rounded
1 A
- Output type (power supply units)
Fixed voltage
- Output voltage (nominal)
24 V DC
- Dim
(L x W x H) 69 x 36 x 94 mm
- Weight
135 g
- Output voltage (max.)
24 V
- Manufacturer part #
39343
- Content
1 pc(s)
- Width
36 mm
- Height
94 mm
- Length
69 mm
- Type
NG AL24/1A
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2595123 Grothe 39343 Power supply unit Content 1 pc(s)
Description
Ng AL24/1A - power supply with potentiometer.Use: For quiescent current door openers
This text is machine translated.
This text is machine translated.
Scope of delivery
- Power supply
