GSR B04042400 Countersink 40 mm HSS cut Cylinder shank 1 pc(s)
EAN:
Part number:
Item no:
Product type
Countersink
DIN standard
DIN 335-C
Ø
40 mm
Material
HSS
Material suitability
Steel
Highlights & Details
Countersink HSSG 40 mm CBN DIN 335 C/90°
- Nominal diameter 40 mm
- DIN standard DIN 335
- Made from HSS
- Shaft type: Cylinder shaft
- Shaft DM 15 mm
Technical specifications
- Product type
Countersink
- DIN standard
DIN 335-C
- Ø
40 mm
- Angle
90°
- No. of blades
3
- Material
HSS
- Material properties
cut
- Material suitability
Steel
- Tool holder
Cylinder shank
- Shank Ø
15 mm
- Content
1 pc(s)
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3730607 GSR B04042400 Countersink 40 mm HSS cut Cylinder shank 1 pc(s)
Description
Countersink CBN according to DIN 335 C, 90°, HSSG Three-cut design for rattle-free sinking, clean deburring and precise lowering of 90° seats (counter-sunk screws). Precision-ground HSS provides high dimensional stability, smooth surfaces and good durability. Cylinder shank for clamping and drill chuck. Suitable for non-alloy and low alloy steels, non-ferrous metals and cast iron; optimal results with emulsion or cutting oil.
