GUDE 1141-1 Socket Black
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
The Expert Power control 1141 is a 4-way switched PDU with integrated measuring and monitoring functionality. Four AV devices can be used with St..
- 4 load outputs at the device switchba, or SNMP, HTTP(s), Modbus
- Integrated web server
- Connection for plug-n-play sensors
- 2 Power counters
- Input-side measurement
Technical specifications
- Product group: Socket strips
- Product type: IP Power switch
- Colour, black
- Function: Remote switching via IP
- Design: Desktop
- Max. load carrying capacity 2000W
- Max. voltage 230V
- On/off switch: No.
- Switch type IP
- Number of socket pots: 4
- Number of outputs/angle 4 x IEC320 C13
- Socket type IEC320 C13, cold devices, 10A
- Material (casing): Metal
- Colour (housing): Black
- Connection cable: --
- Colour (cable): Black
- Plug IEC320 C13 /C14, cold devices
- Plug type IEC320 C14, cold devices, 10A
- Voltage surge protection: Yes
- Technical features: Web Frontend
- Mains connection: Cold-device connection
- Min. Operating temperature 0 °C
- Max. operating temperature: 50 °C
- Height: 43 mm
- Width 95 mm
- Depth: 187 mm
- Weight: 0.88 kg
- Packaging height 80 mm
- Package width 260 mm
- Packaging depth 290 mm
- Package weight: 1,382 kg
- Gross weight: 1.382
- Product type
Socket
- Outlets
4
- Factory colour
Black
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3797317 GUDE 1141-1 Socket Black
User & Safety Instructions
User & Safety Instructions 3797317 GUDE 1141-1 Socket Black
Description
The Expert Power control 1141 is a 4-way switched PDU with integrated measuring and monitoring functionality. Four AV devices can be supplied with power and switched individually. Easy and quick setup with free drivers for leading AV and IT control systems. Precise power measurement and monitoring of temperature and humidity through plug-n-play sensors. Remote restart and automatic switching of power supply. 4 load outputs can be switched individually at the device, via HTTP(S), SNMP, Modbus TCP as well as via command line interface over Telnet, SSH and MQTT. Switch state and switch-on delay (0...9999 seconds) adjustable for every power connection after power failure. Peak currents in case of simultaneous switching operations are prevented by an automatic latency of 1 second. Programmable schedules and switch-on and switch-off sequences - 2 channel watchdog, each Power port can be assigned a separate watchdog. Load outputs can be switched when preset sensor thresholds are exceeded. Connection for plug-n-play sensors for environmental monitoring (temperature, humidity, air pressure). Input side measurement of current, voltage, phase angle, power factor, frequency, Active, apparent and reactive power. 2 energy counters, one counter counts permanently, the other is resettable
This text is machine translated.
Scope of delivery
- Adapter, instructions
