GUDE 8031-1 Socket Black
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Güde Expert Power Control 8031 Power Distribution Unit (PDU) 8 AC Outputs Black
- Meter, Changed Black
- LED
- 8 AC-outputs C13-coupler
Technical specifications
- Number of AC outputs: 8 AC outputs
- Product type
Socket
- Outlets
8
- Factory colour
Black
- Dim
(W x H x D) 439 x 44 x 195 mm
- Width
439 mm
- Height
44 mm
- Depth
195 mm
- Content
1 pc(s)
- Cable length
0 mm
- Version
Mains cable
- Cable use
Current
- Load (max.)
10 A
- 10/100/1000 Mbps ports
3 x
- Safety
SNMP
SNMPv3
- Weight
2.9 kg
- UKCA
yes
- Operating temperature (T-T)
0 - 50 °C
- Serial ports quantity
1
- Manual
yes
- Firmware upgradeable
yes
- Operating relative humidity (H-H)
0 - 95 %
- Storage temperature (T-T)
-20 - 70 °C
Documents & Downloads
Datasheet
Datasheet 3797244 GUDE 8031-1 Socket Black
User & Safety Instructions
User & Safety Instructions 3797244 GUDE 8031-1 Socket Black
Description
Expert Power control 8031
These Power ports are each switched separately via a web interface, via the serial interface, via SNMP or the button on the device. It supports SNMPv3, SSL and IPv6, as well as Telnet, Radius and Modbus TCP. The Expert Power control 8031 has two integrated energy counters. The measurement of a large number of electrical variables makes it possible for the user to recognize and exploit power saving potentials in the IT environment. In addition, the operator receives warning messages when fault currents occur (differential current measurement type A). This allows preventive maintenance before downtime occurs. The switched PDUs have two built-in energy counters. The measurement of a large number of electrical variables makes it possible for the user to recognize and exploit power saving potentials in the IT environment. In addition, the operator receives warning messages when fault currents occur (differential current measurement type A). This allows preventive maintenance before downtime occurs.
This text is machine translated.
Features
- Switching and controlling servers and IT devices in the server room and data center
- Switch network or media technology devices by media controls of well-known AV manufacturers
- (Atlanta, Barco, Crestron, Extron, Neets)
- Remotely restart PCs, servers, routers, and switches
- Reduce the power consumption of standby devices through schedule control
- Network monitoring through integration with monitoring software (PRTG, Icinga, Nagios, Power IQ, Tivoli)
- Environment monitoring by connected sensors (temperature, humidity and air pressure)
- Industrial environments: Production sites, warehouses or production rooms
- IT installations: Technical rooms, data centers, 19" cabinets or server rooms
- AV environments: Huddle rooms, conference rooms, theater/lecture halls, LED walls or digital signage systems
Scope of delivery
- Expert Power control, connection cable (protective contact - IEC C19) Quick start guide
