GUDE 8311-3 Socket Black
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
8-way metered PDU with integrated measurement/evaluation options for TCP/IP networks...
- 8 load outputs (C13) on the front of the device
- Measuring: Current, voltage, phase angle, power factor etc.
- 2 Energy counters, one meter permanent, one counter can be reset
- Connection for optional sensors for environment monitoring
- Radius and Modbus TCP protocol, IPv6 ready
Technical specifications
- Product group: Socket strips
- Product type: Energy meter
- Colour, black
- Length: 1.5 m
- Function: Energy meter
- Dimensions (HxWxD) 44 x 434 x 44 mm
- Height: 44 mm
- Width 434 mm
- Depth: 44 mm
- Weight: 1.5 kg
- Packaging height 90 mm
- Package width 150 mm
- Packaging depth 560 mm
- Package weight: 1.23 kg
- Gross weight: 1.23
- Product type
Socket
- Factory colour
Black
- Content
1 pc(s)
- Cable length
1.50 m
- Keyboard layout
German, QWERTZ
- Weight
1.23
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3797294 GUDE 8311-3 Socket Black
User & Safety Instructions
User & Safety Instructions 3797294 GUDE 8311-3 Socket Black
Description
8-way metered PDU with integrated measurement/evaluation options for TCP/IP networks 8 load outputs (IEC C13) on the front panel . Measurement of current, voltage, phase angle, power factor, frequency, Active, apparent and reactive power. 2 energy meters, one counter counts permanently, the other counter can be reset. Illuminated, two-line LCD display. Connection for optional sensors for surrounding monitoring (temperature, humidity and air pressure) Easy and flexible configuration via web browser, Windows or Linux program. Firmware update possible during operation via Ethernet. IPv6-ready. HTTP/HTTPS, E-MAIL (SSL, STARTTLS), DHCP, SYSLOG. SNMPv1, v2c, v3 (get/trap). TLS 1.0, 1.1, 1.2. Radius and Modbus TCP protocol is supported. Configuration and control via Telnet. Low internal consumption Developed and manufactured in Germany
This text is machine translated.
Features
- Gude Expert PDU Energy 8311-3 - power distribution unit
- Device type: Power distribution unit - rack - mountable
- Rack size: 48.3 cm (19") - 1U
- Weight: 1.1 kg
- Input connections: 1 x Power IEC 60320 C13
- Output points : 8 x Power IEC 60320 C13 10 A.
- Network : Ethernet 10/100
- Remote management protocol : SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, Modbus
- Dimensions (width x depth x height): 43.5 cm x 4.5 cm x 4.5 cm
Scope of delivery
- Expert PDU Energy 8311-3, Quick Start Guide
