Buy GW Instek PEL-3021 Electrical load 150 V DC 35 A 175 W

Electronic load device with a colour display, showing voltage '0.000V', current '0.000A', with numerous buttons for control.

Laboratory power supply with digital display. Shows voltage 0.00V, current 0.00A and power 0.00W. Switches and connections on front panel.

1/2

Datasheet (PDF)

Available soon

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 2,600.84 / piece)

€ 2,600.84

plus VAT.

Report legal concerns

Technical specifications

Type: PEL-3021

Input voltage: 100 - 230 V AC

Product type: Electrical load

Min. input voltage: 100 V AC

Input voltage (max.): 230 V AC

Load input current (max.): 35 A

Max. non-stop power rating: 175 W

Dim: (W x H x D) 215 x 124 x 400 mm

Max. input voltage: 150 V DC

Weight: 6 kg

: Manufacturer's standards (no certificate)

Non-stop power rating: 0.175 W

Inputs: IEC 320 C14

Load input voltage (min.): 1.5 V DC

Min. load input current: 0.00001 A

Load connection: Screw terminals (front)
Screw terminals (rear)

Width: 215 mm

Height: 124 mm

Depth: 400 mm

Documents & Downloads

Datasheet

Datasheet 1321047 GW Instek PEL-3021 Electrical load 150 V DC 35 A 175 W

User & Safety Instructions

User & Safety Instructions 1321047 GW Instek PEL-3021 Electrical load 150 V DC 35 A 175 W

Information

Information 1321047 GW Instek PEL-3021 Electrical load 150 V DC 35 A 175 W

Description

The single-channel PEL-3000-series are electronically controlled high-speed loads for DC voltages. Due to the extremely fast rule times are the devices ideal for quick-switched power supplies and extensive load simulations can be used. Through the wide input range from 1.5 to 150 V/DC, the units are also suitable for charging systems and solar applications.

This text is machine translated.

Features

4 Base Load functions: Constant current (CC), constant voltage (CV), constant resistance (CR), constant power (CP)
3 combined load functions: Constant current and voltage (CC + CV), constant resistance and voltage (CR+CV), constant power and voltage (CP + CV)
Parallel connection of up to 5 typgleichen loads
Go/No Go-Monitoring-Function
Current monitoring and timer function
Interface: USB/RS232/analogue
Protective devices: adjustable low-voltage protection, overvoltage protection, overcurrent protection, Uberleistungsschutz, overheating protection, polarity reversal protection.
