GW Instek PSU 100-15 19" bench PSU (adjustable voltage) 100 V (max.) 15 A (max.) 1500 W LAN, RS232, USB , RS485 programm
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
GW Instek PSU 100-15 19" bench PSU (adjustable voltage) 100 V (max.) 15 A (max.) 1500 W LAN, RS232, USB , RS485 program
- No. of outputs 4 x
- 100 V (max.) / 15 A (max.)
- 1500 W
- LAN, RS232, USB , RS485
- programmable, slim type
Technical specifications
- Type
PSU 100-15
- No. of outputs
4 x
1500 W
- Technology
SMPSU
- Interfaces
LAN
RS232
USB
RS485
- Features
programmable
slim type
- Dim
(L x W x H) 447.2 x 423 x 43.6 mm
- Weight
8.7 kg
- Height
43.6 mm
- Length
447.2 mm
- Width
423 mm
Manufacturer's standards (no certificate)
- Input voltage
230 V AC
- Max. output current
15 A
- Output voltage (max.)
100 V
- Max. temperature
50 °C
- Min. temperature
0 °C
- Product type
19" bench PSU (adjustable voltage)
Documents & Downloads
Datasheet
Datasheet 3221887 GW Instek PSU 100-15 19" bench PSU (adjustable voltage) 100 V (max.) 15 A (max.) 1500 W LAN, RS232, USB , RS485 programm
User & Safety Instructions
User & Safety Instructions 3221887 GW Instek PSU 100-15 19" bench PSU (adjustable voltage) 100 V (max.) 15 A (max.) 1500 W LAN, RS232, USB , RS485 programm
Information
Information 3221887 GW Instek PSU 100-15 19" bench PSU (adjustable voltage) 100 V (max.) 15 A (max.) 1500 W LAN, RS232, USB , RS485 programm
Description
The introduction of PSU-HV is intended to complement the existing PSU series to meet the requirements of high voltage applications. In addition, the original maximum output voltage of 60V is extended to the maximum voltage of 600V and the maximum power of 1560 watts.
This text is machine translated.
This text is machine translated.
Features
- C.V. / C.C. Priority; particularly suitable for battery & LED industry
- Adjustable slew-rate
- Series and parallel operation (2 units in series or 4 units in parallel)
- High efficiency and high power density
- 19" rack mount size design
- Standard interface: LAN, RS-232 & RS-485, USB (device / host), analogue
- Control interface
Scope of delivery
- User manual, programming manual on CD-ROM
- Power cable (10A)
- 1 x output terminal cover
- 1 x analogue connector set
- Output terminal M8 screw set (model 6V-60V)
- 1 x cover of the input terminal
- 1 x U handle (RoHS)
- 1 x U holders (left, RoHS)
- 1 x U holder (right. RoHS
