Buy Hager ADS966D RCCB 1-pin 16 A 0.03 A 240 V

A single-pole Hager circuit breaker ADS 966D with blue switch, rated current 16 A, residual current protection 0.03 A.

Product type

RCCB

Release characteristics

Differential current rating

0.03 A

Nominal current - rounded value

16 A

Switch-off capacity

6 kA

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

Residual current circuit breaker, 1 P + N

Rated operating voltage Ue 240V
Nominal current 16 A
Trigger characteristic C
Polart 1P+N

Technical specifications

Product type: RCCB

Release characteristics: C

Differential current rating: 0.03 A

Factory colour: Grey

Dim: (W x H x D) 40.0000 x 80.0000 x 95.0000 mm

Content: 1 pc(s)

Nominal current: 16 A

Nominal current - rounded value: 16 A

Switch-off capacity: 6 kA

Nominal voltage: 240 V

Width: 40.0000 mm

Height: 80.0000 mm

Depth: 95.0000 mm

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 1845609 Hager ADS966D RCCB 1-pin 16 A 0.03 A 240 V

User & Safety Instructions

User & Safety Instructions 1845609 Hager ADS966D RCCB 1-pin 16 A 0.03 A 240 V

Description

Residual current circuit breaker switch with quick connect terminal according to DIN EN 60898-1, VDE 0641-11, at the outlet up to 20 A and the access to 63 A. Protection against contact DIN VDE 0106 Part 100, blue test button and fault current display. Simple individual removal from the phase rail network. With VDE.
Suitable for subsequent installation of additional facilities. Labelling option directly on the device.

This text is machine translated.
