Hager HHA040H Circuit breaker 1 pc(s) Piece
EAN:
Part number:
Item no:
Product type
Circuit breaker
Connection
Screw terminal
Packaging type
Piece
Type
HHA040H
No. of pins
3-pin
Datasheet (PDF)
Technical specifications
- Packaging type
Piece
- Product type
Circuit breaker
- Type
HHA040H
- No. of pins
3-pin
- Connection
Screw terminal
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3194471 Hager HHA040H Circuit breaker 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3194471 Hager HHA040H Circuit breaker 1 pc(s) Piece
Description
Circuit breaker H3 X160 TM ADJ 3P3D 40A 25kA CTC. Circuit breaker according to DIN EN 60947-2 size X160, with thermal (adjustable) and magnetic (fixed) tripping for the protection of electrical systems and networks. Mounting on DIN rail or mounting plate. The three different operating modes can be recognized at the position of the toggle (ON = top, OFF = bottom, activated = middle position). Frame terminals for Cu cables are included as standard. The switches have a mechanical test button. The function of the circuit breakers can be extended by means of various accessories.
