Hager HHA101H Circuit breaker 1 pc(s) Adjustment range (amperage): 100 A (max)
EAN:
Part number:
Item no:
Product type
Circuit breaker
Amperage adjustment range (max.)
100 A
Connection
Screw terminal
Type
HHA101H
Adjustment range (amperage)
100 A (max)
Datasheet (PDF)
Technical specifications
- Product type
Circuit breaker
- Type
HHA101H
- Amperage adjustment range (max.)
100 A
- Adjustment range (amperage)
100 A (max)
- No. of pins
4-pin
- Mounting type
DIN rail
- Features
+ test button
- Connection
Screw terminal
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3194478 Hager HHA101H Circuit breaker 1 pc(s) Adjustment range (amperage): 100 A (max)
User & Safety Instructions
User & Safety Instructions 3194478 Hager HHA101H Circuit breaker 1 pc(s) Adjustment range (amperage): 100 A (max)
Description
Power switch h3 X160 TM ADJ 4P4D N0-100% 100A 25kA CTC. Circuit breaker according to DIN EN 60947-2 size X160, with thermal (adjustable) and magnetic (fixed) tripping for the protection of electrical systems and networks. Mounting on DIN rail or mounting plate. The three different operating modes can be recognized at the position of the toggle (ON = top, OFF = bottom, activated = middle position). Frame terminals for Cu cables are included as standard. The switches have a mechanical test button. The function of the circuit breakers can be extended by means of various accessories.
