Hager HNA080H Circuit breaker 1 pc(s) Adjustment range (amperage): 80 A (max)
EAN:
Part number:
Item no:
Product type
Circuit breaker
Amperage adjustment range (max.)
80 A
Type
HNA080H
Adjustment range (amperage)
80 A (max)
No. of pins
3-pin
Datasheet (PDF)
Technical specifications
- Product type
Circuit breaker
- Type
HNA080H
- Amperage adjustment range (max.)
80 A
- Adjustment range (amperage)
80 A (max)
- No. of pins
3-pin
- Mounting type
DIN rail
- Features
+ test button
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3194489 Hager HNA080H Circuit breaker 1 pc(s) Adjustment range (amperage): 80 A (max)
User & Safety Instructions
User & Safety Instructions 3194489 Hager HNA080H Circuit breaker 1 pc(s) Adjustment range (amperage): 80 A (max)
Description
Circuit breaker H3 X160 TM ADJ 3P3D 80A 40kA CTC. Circuit breaker according to DIN EN 60947-2 size X160, with thermal (adjustable) and magnetic (fixed) tripping for the protection of electrical systems and networks. Mounting on DIN rail or mounting plate. The three different operating modes can be recognized at the position of the toggle (ON = top, OFF = bottom, activated = middle position). Frame terminals for Cu cables are included as standard. The switches have a mechanical test button. The function of the circuit breakers can be extended by means of various accessories.
