Hager HNA100H Circuit breaker 1 pc(s) Adjustment range (amperage): 63 - 100 A Switching voltage (max.): 415 V AC Piece
EAN:
Part number:
Item no:
Product type
Circuit breaker
Amperage adjustment range (max.)
100 A
Packaging type
Piece
Type
HNA100H
Amperage adjustment range (min.)
63 A
Datasheet (PDF)
Technical specifications
- Packaging type
Piece
- Product type
Circuit breaker
- Type
HNA100H
- Amperage adjustment range (min.)
63 A
- Amperage adjustment range (max.)
100 A
- Adjustment range (amperage)
63 - 100 A
- No. of pins
3-pin
- Switching voltage (max.)
415 V AC
- Mounting type
DIN rail
- OCR type
TM
- Features
+ test button
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3194491 Hager HNA100H Circuit breaker 1 pc(s) Adjustment range (amperage): 63 - 100 A Switching voltage (max.): 415 V AC Piece
User & Safety Instructions
User & Safety Instructions 3194491 Hager HNA100H Circuit breaker 1 pc(s) Adjustment range (amperage): 63 - 100 A Switching voltage (max.): 415 V AC Piece
Description
Circuit breaker H3 X160 TM ADJ 3P3D 100A 40kA CTC. Circuit breaker according to DIN EN 60947-2 size X160, with thermal (adjustable) and magnetic (fixed) tripping for the protection of electrical systems and networks. Mounting on DIN rail or mounting plate. The three different operating modes can be recognized at the position of the toggle (ON = top, OFF = bottom, activated = middle position). Frame terminals for Cu cables are included as standard. The switches have a mechanical test button. The function of the circuit breakers can be extended by means of various accessories.
