Hager HTN363C HTN363C Main RCCB 63 A 400 V
EAN:
Part number:
Item no:
Product type
Main RCCB
Number of pins
3
Nominal current - rounded value
63 A
Nominal current
63 A
Content
1 pc(s)
Datasheet (PDF)
Technical specifications
- Product type
Main RCCB
- Number of pins
3
- Nominal current - rounded value
63 A
- Nominal current
63 A
- Content
1 pc(s)
- Nominal voltage
400 V
- Weight
0
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3199556 Hager HTN363C HTN363C Main RCCB 63 A 400 V
User & Safety Instructions
User & Safety Instructions 3199556 Hager HTN363C HTN363C Main RCCB 63 A 400 V
Description
SLS switch 3-pin CS-characteristic 63A for DIN rail assembly. SH-Switch according to DIN VDE 0641-21 and norm size DIN 43880, size 2. SLS in 1-pin or 3-pin design, single-pin switching, with separate contact status indicator. For direct mounting on a DIN rail. The standard (no suggestions) allows for the following locks: For the customer against unintentional or intentional switching, for the installer with a padlock while working in the system, for the VNB with sealing wire, padlock or special key.
