Hahn BV EI 422 1260 PCB mount transformer 1 x 230 V 2 x 12 V AC 6.0 VA
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Transformer P: 230V S: 2x12V/6.0VA
- 1 x 230 V
- 2 x 12 V AC
- 6.0 VA
Technical specifications
- Product type
PCB mount transformer
- Output voltage
12 V AC
- Output voltage (number x voltage)
2 x 12 V AC
- No. of inputs
1 x
- No. of outputs
2 x
- Input voltage
230 V
- Input voltage (number x voltage)
1 x 230 V
6.0 VA
- Width
37.20 mm
- Height
32.30 mm
- Length
44.30 mm
- Type
BV EI 422 1260
- Dim
(L x W x H) 44.30 x 37.20 x 32.30 mm
- Frequency
50 - 60 Hz
- Weight
200 g
- Content
1 pc(s)
- RoHS-compliant
Yes
- Max. ambient temperature
+70 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2827691 Hahn BV EI 422 1260 PCB mount transformer 1 x 230 V 2 x 12 V AC 6.0 VA
User & Safety Instructions
User & Safety Instructions 2827691 Hahn BV EI 422 1260 PCB mount transformer 1 x 230 V 2 x 12 V AC 6.0 VA
