Hahn BV EI 481 1119 PCB mount transformer 1 x 230 V 2 x 12 V AC 10.0 VA
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Transformer P: 230V S:2x12V/10.0VA
- 1 x 230 V
- 2 x 12 V AC
- 10.0 VA
Technical specifications
- Product type
PCB mount transformer
- Output voltage
12 V AC
- Output voltage (number x voltage)
2 x 12 V AC
- No. of inputs
1 x
- No. of outputs
2 x
- Input voltage
230 V
- Input voltage (number x voltage)
1 x 230 V
10.0 VA
- Width
50.70 mm
- Height
34.60 mm
- Length
42.70 mm
- Type
BV EI 481 1119
- Dim
(L x W x H) 42.70 x 50.70 x 34.60 mm
- Frequency
50 - 60 Hz
- Weight
300 g
- Content
1 pc(s)
- RoHS-compliant
Yes
- Max. ambient temperature
+70 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2827694 Hahn BV EI 481 1119 PCB mount transformer 1 x 230 V 2 x 12 V AC 10.0 VA
