Hahn BV EI 541 1126 PCB mount transformer 1 x 230 V 1 x 18 V AC 16.0 VA
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
TRANSFORMER P: 230V S:18V/16.0VA
- 1 x 230 V
- 1 x 18 V AC
- 16.0 VA
Technical specifications
- Product type
PCB mount transformer
- Output voltage
18 V AC
- Output voltage (number x voltage)
1 x 18 V AC
- No. of inputs
1 x
- No. of outputs
1 x
- Input voltage
230 V
- Input voltage (number x voltage)
1 x 230 V
16.0 VA
- Width
56.80 mm
- Height
38.80 mm
- Length
47.70 mm
- Type
BV EI 541 1126
- Dim
(L x W x H) 47.70 x 56.80 x 38.80 mm
- Frequency
50 - 60 Hz
- Weight
400 g
- Content
1 pc(s)
- RoHS-compliant
Yes
- Max. ambient temperature
+70 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2827704 Hahn BV EI 541 1126 PCB mount transformer 1 x 230 V 1 x 18 V AC 16.0 VA
