Hahn BV UI 21 0011 PCB mount transformer 1 x 230 V 1 x 3 V AC 1.0 VA
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
TRANSFORMER P: 230V S:3V/1.0VA
- 1 x 230 V
- 1 x 3 V AC
- 1.0 VA
Technical specifications
- Product type
PCB mount transformer
- Output voltage
3 V AC
- Output voltage (number x voltage)
1 x 3 V AC
- No. of inputs
1 x
- No. of outputs
1 x
- Input voltage
230 V
- Input voltage (number x voltage)
1 x 230 V
1.0 VA
- Width
33.80 mm
- Height
14.90 mm
- Length
29.30 mm
- Type
BV UI 21 0011
- Dim
(L x W x H) 29.30 x 33.80 x 14.90 mm
- Frequency
50 - 60 Hz
- Weight
50 g
- Content
1 pc(s)
- RoHS-compliant
Yes
- Max. ambient temperature
+70 °C
