HARTING 09181109422 PCB connector straight Contact spacing: 2.54 mm Total number of pins: 10 No. of rows: 2 1 pc(s) Sing
EAN:
Part number:
Item no:
Packaging type
Single
Connector type
straight
Product type
PCB connector
CS
2.54 mm
No. of rows
2
Datasheet (PDF)
Highlights & Details
Printed circuit board connector
- Total number of pins 10
- No. of rows 2
- Content 1 pc(s)
Technical specifications
- SEK low-profile
- Component: Circuit board connector
- Contact description: Straight
- Connection type: Solder connection;IDC terminals
- Type of connection: Circuit board to cable
- Number of contacts: 10
- Length of the Pins 2.9 mm
- Plug contact series 2
- Pitch, connection side 2.54 mm
- Rated current 2.6 A
- Insulation resistance >109 Ω
- Continuous resistance ≤ 35 mΩ
- Temperature limit: -55 ... +105 °C
- Test voltage Ueff 1 kV
- Insulation material group II (400 ≤ CTI < 600)
- Material application: Thermoplastic molding material (PBT)
- Colour insert: Grey
- Material contacts: Copper alloy
- Contact surface: Sn over Ni connectors side; Sn over Ni connection side
- Material flammability class acc. To UL 94: V-0
- IEC 60603-13 standard
- Net weight: 2.524 g
- Pitch, plug-side 1.27 mm
- Notes: For IDC flat cable with a 1.27 mm (0.050") pitch;AWG 28/7
- Height 5.5 mm
- Packaging type
Single
- Connector type
straight
- Product type
PCB connector
- Features
straight
- CS
2.54 mm
- No. of rows
2
- Total number of pins
10
- Nominal current
2.6 A
- Contact material
Copper alloy
- Content
1 pc(s)
- Connection
Soldering
Cut & Clip connector
- Type
09 18 110 9422
- Case material
Thermoplastic
- Manufacturer part #
09181109422
- Factory colour
Grey
- Insulation material
Thermoplastic
- Board contact surface
Tin plated
- Connector contact surface
Tin plated
- Height
5.5 mm
- Max. temperature
+105 °C
- Min. temperature
-55 °C
- Resistance
≤ 35 mΩ
- Insulation resistance
109 Ω
- Pin length
2.9 mm
Printed circuit board to cable
Grey
10
-55-105 °C
V0
Soldering connection
Tin
2.9 mm
2.54 mm
2
1.27 mm
Thermoplastic
90° (upwards vertical)
Other
2.6 A
Documents & Downloads
Datasheet
Datasheet 3000939 HARTING 09181109422 PCB connector straight Contact spacing: 2.54 mm Total number of pins: 10 No. of rows: 2 1 pc(s) Sing
Datasheet 3000939 HARTING 09181109422 PCB connector straight Contact spacing: 2.54 mm Total number of pins: 10 No. of rows: 2 1 pc(s) Sing
User & Safety Instructions
User & Safety Instructions 3000939 HARTING 09181109422 PCB connector straight Contact spacing: 2.54 mm Total number of pins: 10 No. of rows: 2 1 pc(s) Sing
Description
PCB connector, solder connection, IDC insulation displacement connector, rated current 2.6 A, thermoplastic molded (PBT), gray, contacts: 10
