A grey electrical connection block with three connection openings and a screw on the front.

A grey electrical connection block with three connection openings and a screw on the front.

Product type

Pin inset

Series

Han® A

Connection

Han Quick-Lock®

Total no. of pins

3 + PE

Core cross section (min.)

0.5 mm²

Datasheet (PDF)

English

HARTING

Unavailable

39 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Technical specifications

Product type: Pin inset

Factory colour: Pebble grey (RAL 7032)

Series: Han® A

Features: tin-plated contacts

Connection: Han Quick-Lock®

Number of pins: 3

Total no. of pins: 3 + PE

Core cross section (min.): 0.5 mm²

Core cross section (max.): 2.5 mm²

Mating cycles: 500

Series: Han A®

Content: 1 pc(s)

Max. temperature: 125 °C

Min. temperature: -40 °C

Leading contact (PE): Yes

: FALSE

: 3

: Bus

: -40-125 °C

: V0

: 4 kV

: Spring clamp connection

: Silver

: 3

: FALSE

: 0.5-2.5 mm²

: 0.5-2.5 mm²

: TRUE

: Other copper alloys

: Thermoplastic

: 10 A

: Thermoplastic

: 500

: 3

UKCA: not relevant
