Hazet 6109-2CT 6109-2CT Torque wrench Forward/reverse ratchet 1/4" (6.3 mm) 4 - 40 Nm
EAN:
Part number:
Item no:
Highlights & Details
HAZET Torque wrench 6109-2CT
- With square opening
- Triggering accuracy ± 4%
Technical specifications
- Product type
Torque wrench
- Features
Forward/reverse ratchet
- Downforce
1/4" (6.3 mm)
- Torque (min.)
4 Nm
- Torque (max.)
40 Nm
- Trigger accuracy
2 %
- Graduation
0.4 Nm
- Length
256 mm
- DIN standard
DIN EN ISO 6789
- Weight
400 g
- Width
40 mm
- Height
40 mm
- Standards
DIN EN ISO 6789:2003; Square according to DIN 3120 A, ISO 1174-1 A
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 804660 Hazet 6109-2CT 6109-2CT Torque wrench Forward/reverse ratchet 1/4" (6.3 mm) 4 - 40 Nm
Description
Features
- With automatic close-gap release, palpable and audible when torque setting is reached
- Easy and safe adjustment of the desired torque value by turning the handle
- Release accuracy tolerance (in direction of actuation)± 2% of scale value - 6106-1 CT: ± 4% release accuracy tolerance
- Application: engines, gearboxes, machines, industry, model making
- Without signal transmitter
- DIN EN ISO 6789:2003 (D), Square according to DIN 3120, ISO 1174-1
- Made in Germany
- Total length (for eClass): 256 mm
- Output: Square, solid 63 mm (1/4 inch)
- Net weight: 04 kg
