Headband electret microphone JTS CM-304SP Transfer type (details):Corded
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Net weight: 0.069 kg
- Ass. Operating temperature 0-40 °C
- Weight: 44 g,30 g (without cable)
- Gross weight: 0.185 kg
- Max. Sound pressure 130 dB
- Connection 4-Pol-Mini-XLR
- Characteristic: Ball
- Sensitivity 22.4 mV/Pa
- Type: Head microphone
- Transmission type: Cable
- System: Back-electret
- Audio frequency range 50-20000 Hz
- Supply 1,5-9 V
- Nominal impedance 1.8 kΩ
- Cable 1.5 m
- Product type
Headband electret microphone
- Transfer type
Corded
- Characteristics
Ball
- Impedance
1.8 kΩ
- Cable length
1.5 m
- Connector
4-Pol-Mini-XLR
- Weight
44 g
- Frequency range
50-20000 Hz
Documents & Downloads
Datasheet
Datasheet 3340615 Headband electret microphone JTS CM-304SP Transfer type (details):Corded
User & Safety Instructions
User & Safety Instructions 3340615 Headband electret microphone JTS CM-304SP Transfer type (details):Corded
Description
Electret headphone microphone
For fitness and aerobics
Back-Elektret microphone capsule in ball characteristic Splash-protection Drip ring (protects the capsule additionally against moisture) Flexible capsule arm Higher wearing comfort through adjustable head bracket Secure hold in case of extreme applications like Aerobic or spinning Head band microphone with connection 2.5-mm-jack plug Detachable 500-m connection cable with 1,5-9-mm-jack plug with thread and 4-pin mini-XLR connection on optional phantom-power adapter (MA-1.5) or JTS V-pocket transmitter (2.5) Rubber grommet to protect the plug connection to the pocket transmitter from moisture
This text is machine translated.
For fitness and aerobics
Back-Elektret microphone capsule in ball characteristic Splash-protection Drip ring (protects the capsule additionally against moisture) Flexible capsule arm Higher wearing comfort through adjustable head bracket Secure hold in case of extreme applications like Aerobic or spinning Head band microphone with connection 2.5-mm-jack plug Detachable 500-m connection cable with 1,5-9-mm-jack plug with thread and 4-pin mini-XLR connection on optional phantom-power adapter (MA-1.5) or JTS V-pocket transmitter (2.5) Rubber grommet to protect the plug connection to the pocket transmitter from moisture
This text is machine translated.
Features
- Type: Head microphone
- Transmission type: Cable
- Characteristic: Ball
- System: Back-electret
- Audio frequency range 50-20000 Hz
- Nominal impedance 1.8 kΩ
- Sensitivity 22.4 mV/Pa
- Max. Sound pressure 130 dB
- Supply 1,5-9 V
- Ass. Operating temperature 0-40 °C
- Weight: 44 g,;30 g (without cable)
- Cable 1.5 m
- Connection 4-Pol-Mini-XLR
- Packaging dimensions (W x H x L) 0.187 x 0.1 x 0.143 m
- Gross weight: 0.185 kg
- Net weight: 0.069 kg
