Heavy Duty Connectors, HDC insert, ConCept module
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
System bus module
Type
HDC CM BUS SV GCA M
Manufacturer part #
1014080000
Connection
Connector
Highlights & Details
Heavy Duty Connectors, HDC insert, ConCept module
- HDC CM BUS SV GCA M
Our service for you
Technical specifications
- Packaging type
Piece
- Type
HDC CM BUS SV GCA M
- Product type
System bus module
- Manufacturer part #
1014080000
- Connection
Connector
- Content
1 pc(s)
- Material
Zinc (die-cast)
- Height
3.9 mm
- Length
33.5 mm
- Width
21.5 mm
- Weight
8 g
21.5
3.9 m
V0
FALSE
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 195646 Heavy Duty Connectors, HDC insert, ConCept module
Description
The ConCept-CSB module is a double module and takes up two slots in the ConCept module frame. The ConCept-CSB module consists of a module carrier that is capable of holding two contact carriers. The contact carrier is manufactured with a die-cast zinc alloy which provides it with excellent shielding capabilities. The crimp contacts are insulated from the contact carrier and mounted in a plastic insert. A variety of pole counts – 1, 4 and 8 poles – are available to ensure compatibility with a wide range of applications.
