Helios Ventilatoren 01948 Variac 1 x 230 V 1 x 80 V, 100 V, 130 V, 170 V, 230 V 3 A
EAN:
Part number:
Item no:
Highlights & Details
HELIOS fans Transformer speed controller with motor protection unit MWS 3
- 1 x 230 V
- 1 x 80 V, 100 V, 130 V, 170 V, 230 V
- 3 A
Technical specifications
- Number of phases: 1
- Number of steps: 5
- Base element without cover: no.
- Operating mode: Rotary knob
- Lighting: Check (off)
- Power control infinitely variable: no.
- With temperature sensor: Yes
- Nominal current 3 A
- Protection class: IP54
- Product type
Variac
- Output voltage
80 V
100 V
130 V
170 V
230 V
- Output current
3 A
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage
230 V
- Connection
Punchdown block
- Width
200 mm
- Height
254 mm
- Length
98 mm
- Dim
(L x W x H) 98 x 200 x 254 mm
- Output voltage (number x voltage)
1 x 80 V, 100 V, 130 V, 170 V, 230 V
- Input voltage (number x voltage)
1 x 230 V
- Content
1 pc(s)
- Mounting type
Surface-mount
- Protection class
IP54
- Features
adjustable
- Type
MWS 3
- Max. ambient temperature
40 °C
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2296000 Helios Ventilatoren 01948 Variac 1 x 230 V 1 x 80 V, 100 V, 130 V, 170 V, 230 V 3 A
Description
5-stage speed controller for connecting thermal contacts (wired on terminal board) of one or more fans up to the rated load. With integrated tripping unit and indicator light. Recommissioning after fault above 0 position. Switchable voltages: 0/80/100/130/170/230 volt. Ambient temperature max. 40 °C. Surface-mounted plastic housing, protection class IP 54.
