Buy HellermannTyton 315-13005 Heatshrink + adhesive Black 19 mm 6 mm Shrinkage:3:1 1 m

Shiny black aluminium pipe running diagonally from top left to bottom right. Star-shaped cross-section visible.

Black heat shrink tubes in various diameters, arranged from large to small, displayed on a white background.

1/2

Product type

Heatshrink + adhesive

Nominal inside diameter (pre-shrinkage)

19 mm

Nominal diameter (post-shrinkage)

6 mm

Heatshrink features

Thin-walled

Highly flame-retardant

Content

1 m

Fast track dispatch on Mon, 5 Oct

2 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (1 m = € 47.05)

€ 47.05

plus VAT.

Only 2 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Thin-walled heat-shrink TA 37 3:1

Thin wall adhesive lined heat shrink tubing
Halogen Free
Flame Retarded
Combination of these three (halogen free, adhesive lined and flame retarded) product properties is unique
Tubing conforms to London Underground specification LUL E1042-A6, BS6853

Our service for you

Technical specifications

Product type: Heatshrink + adhesive

Nominal inside diameter (pre-shrinkage): 19 mm

Nominal diameter (post-shrinkage): 6 mm

Factory colour: Black

Shrinkage: 3:1

Heatshrink features: Thin-walled
Highly flame-retardant

Content: 1 m

Material: Polyolefin (irradiated)

Shrink temperature (min.): +150 °C

Min. temperature: -40 °C

Max. temperature: +105 °C

Manufacturer part #: 315-13005

Halogen-free: Yes

RoHS-compliant: Yes

Type: TA37-19/6-BK-1200

Type: Thin-walled

Certification: 1042: A6, corresponds to LUL E conforms to BS 6853

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 546278 HellermannTyton 315-13005 Heatshrink + adhesive Black 19 mm 6 mm Shrinkage:3:1 1 m

Description

Halogen Free, Adhesive Lined, Flame Retarded, Thin Wall heat shrink tubing. The combination of these three (halogen free, adhesive lined and flame retarded) product properties makes TA37 shrink tubing unique. The tubing conforms to London Underground specification LUL E1042-A6, BS6853. This 3:1 shrink ratio tubing offers a wide size range : from 3/1 mm op 120/40 mm. TA37 shrink tubing has a low smoke index and excellent flame retardant properties to meet strict fire security standards in electrical insulation.
