HellermannTyton FKH50A-HIR-BK-C1 Cable mount Self-adhesive, Screw fixing 151-15500 for ribbon cable, + acrylate glue, im
EAN:
Part number:
Item no:
Product type
Cable mount
Fastening method
Self-adhesive
Screw fixing
Material
Polyamide 6.6
Features
for ribbon cable
+ acrylate glue
impact-resistant
Min. temperature
-40 °C
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 2.09
10
8% = € 0.16
€ 1.93
25
11% = € 0.22
€ 1.87
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 2.09 / piece)
€ 2.09
plus VAT.
14-day return policy included
Highlights & Details
HellermannTyton FKH50A-HIR-BK-C1 Cable mount Self-adhesive, Screw fixing 151-15500 for ribbon cable, + acrylate glue, impact-resistant Black 1 pc(s)
- Black
- Cable mount
- Self-adhesive, Screw fixing
Our service for you
Technical specifications
- Flame-retardant according to UL94 HB (without adhesive)
- Product type
Cable mount
- Features
for ribbon cable
+ acrylate glue
impact-resistant
- Fastening method
Self-adhesive
Screw fixing
- Material
Polyamide 6.6
- Min. temperature
-40 °C
- Max. temperature
+80 °C
- Mounting Ø (min.)
3.10 mm
- Mounting Ø (max.)
3.10 mm
- Factory colour
Black
- Halogen-free
Yes
- Content
1 pc(s)
- Manufacturer part #
151-15500
- Dimensions
(L x W x W2) 56.6 x 25 x 22 mm
- RoHS-compliant
Yes
- Type
FKH50A-HIR-BK-C1
- Material (details)
Polyamide 6.6, modified impact-resistant (PA66HIR)
- Type
With adhesive
- Operating temperature
-40 - +80 ºC, short-term - +105 °C (500 h)
Documents & Downloads
Datasheet
Datasheet 540450 HellermannTyton FKH50A-HIR-BK-C1 Cable mount Self-adhesive, Screw fixing 151-15500 for ribbon cable, + acrylate glue, im
User & Safety Instructions
User & Safety Instructions 540450 HellermannTyton FKH50A-HIR-BK-C1 Cable mount Self-adhesive, Screw fixing 151-15500 for ribbon cable, + acrylate glue, im
Description
The flat ribbon cable clip can be attached with either high-quality acrylic tape or M3 screws. The handy quick lock/release allows you to quickly open and close the clamp. The flat ribbon cable clip is made of a high-quality, modified impact resistant polyamide 6.6 and can, therefore, be used in especially dry areas. The flat cable is routed and held securely due to the flat edges and the especially flexible wings.
Hints
Application: The flat ribbon cable clip is used wherever flat cables are applied, e.g. mechanical engineering and apparatus construction, in high-quality PCs and servers.
