Stroke drawing/circuit diagram
1/2
Stroke drawing/circuit diagram
HellermannTyton H126 PVC BK 1000 Cord sleeve Terminal Ø (max.) 5 mm PVC Black 1 pc(s)
EAN:
Part number:
Item no:
Product type
Cord sleeve
Material
PVC
Clamp Ø
4.5 mm
Terminal Ø (max.)
5 mm
Factory colour
Black
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 0.34
30
12% = € 0.04
€ 0.30
50
15% = € 0.05
€ 0.29
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 0.34 / piece)
€ 3.40
plus VAT.
14-day return policy included
Highlights & Details
Cord form of protection sleeve
Our service for you
Technical specifications
- Product type
Cord sleeve
- Factory colour
Black
- Material
PVC
- Length
32 mm
- Width
9 mm
- Height
9 mm
- (Ø)
9 mm
- Dim
(Ø x H) 9 mm x 9 mm
- Clamp Ø
4.5 mm
- Terminal Ø (max.)
5 mm
- Min. temperature
-30 °C
- Max. temperature
60 °C
- Weight
1.4 g
- Halogen-free
No
- Content
1 pc(s)
- Manufacturer part #
634-31260
- Type
H126 PVC BK 1000
- RoHS-compliant
Yes
Documents & Downloads
Datasheet
Datasheet 1505911 HellermannTyton H126 PVC BK 1000 Cord sleeve Terminal Ø (max.) 5 mm PVC Black 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1505911 HellermannTyton H126 PVC BK 1000 Cord sleeve Terminal Ø (max.) 5 mm PVC Black 1 pc(s)
