HELU 17042-500 Data transfer cable 16 x 2 x 1.5 mm² Grey 500 m
EAN:
Part number:
Item no:
Product type
Data transfer cable
No. of leads
32 x
Cross section (each core)
1.5 mm²
Cable features
Shielded
Flame-retardant
Twisted pair cabling (part 1)
Yes (1)
Datasheet (PDF)
Technical specifications
- Weight 1100 kg/km
- Product type
Data transfer cable
- No. of leads
32 x
- Cross section (each core)
1.5 mm²
- Twisted pair cabling (part 1)
Yes (1)
- Cross section
16 x 2 x 1.5 mm²
- Cable features
Shielded
Flame-retardant
- Outside Ø
25 mm
- Factory colour
Grey
- Content
500 m
- Nominal voltage (details)
500 V
- Nominal voltage U0
300 V
- Bend radius (no. of ODs for fixed installation)
5
- Bend radius (no. of ODs for flexible installation)
10
- Sold per metre
No
- Shielded
Yes
- Manufacturer part #
17042-500
- Insulation material
PVC
- Wire ID code
Wire identification according to DIN VDE 0293-334, black conductors with consecutive white digits
- Insulation
PVC
- Core layout
Cu-strand blank, fine-wired according to DIN VDE 0295 Class 5 / IEC 60228 Cl. 5
- RoHS-compliant
Yes
- Min. temperature range (flexible installation)
-15 °C
- Max. temperature range (flexible installation)
80 °C
- Min. temperature range (fixed installation)
-40 °C
- Max. temperature range (fixed installation)
80 °C
- Certification marks
EAC
- Max. length sold by the metre
500 m
- Type
PAAR-CY-OZ 16x2x1,5 GR
Documents & Downloads
Datasheet
Datasheet 2825663 HELU 17042-500 Data transfer cable 16 x 2 x 1.5 mm² Grey 500 m
User & Safety Instructions
User & Safety Instructions 2825663 HELU 17042-500 Data transfer cable 16 x 2 x 1.5 mm² Grey 500 m
Description
For flexible use with free movement without tensile stress and without forced movement in dry, damp and wet rooms, but not outdoors, as connecting line in measurement, control, and signal technology as well as in electronics. Further use in pulse and data technology This type has proven itself especially in applications where high electromagnetic radiation is present, for example, through neighboring cables. EMC = electromagnetic compatibility; to optimize the EMC properties, we recommend that copper braid contacts are made on both sides and over a wide area.
This text is machine translated.
This text is machine translated.
