HELU 29202-100 Wire H07V-K 1 x 10 mm² Rose 100 m
EAN:
Part number:
Item no:
Product type
Wire
No. of leads
1 x
Cross section (each core)
10 mm²
Cable type
H07V-K
Outside Ø
6.80 mm
Technical specifications
- Product type
Wire
- No. of leads
1 x
- Content
100 m
- Cross section (each core)
10 mm²
- Insulation material
PVC
- Cable features
Flame-retardant
- Cable type
H07V-K
- Outside Ø
6.80 mm
- Nominal voltage
750 V
- Manufacturer part #
29202-100
- Factory colour
Rose
- Core layout
Cu-Litze blank, nach DIN VDE 0295 Kl.5, feindrähtig, BS 6360 cl.5, IEC 60228 cl.5
- Nominal voltage U0
450 V
- Test voltage
2500 V
- Cross section
1 x 10 mm²
- Max. temperature range (flexible installation)
+70 °C
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (fixed installation)
+80 °C
- Min. temperature range (fixed installation)
-30 °C
- Type
29202-100
- Standards
EAC; VDE
