HELU 32005-500 Earth cable NYY-J 1 G 25 mm² Green-yellow 500 m
EAN:
Part number:
Item no:
Product type
Earth cable
Cable type
NYY-J
No. of leads
1 G
Cross section (each core)
25 mm²
Content
500 m
Technical specifications
- Product type
Earth cable
- Cable type
NYY-J
- No. of leads
1 G
- Cross section (each core)
25 mm²
- Cross section
1 G 25 mm²
- Cable features
PVC coating
for underground installation
Flame-retardant
round wire
multi-core
- Factory colour
Green-yellow
- Outside Ø
12.00 mm
- Content
500 m
- Nominal voltage
1000 V
- Nominal voltage U0
600 V
- Bend radius (no. of ODs for fixed installation)
15
- Packaged
Yes
- Sold per metre
No
- Halogen-free
No
- Shielded
No
- Manufacturer part #
32005-500
- Insulation material
PVC
- RoHS-compliant
Yes
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (flexible installation)
+50 °C
- Min. temperature range (fixed installation)
-40 °C
- Max. temperature range (fixed installation)
+70 °C
- Certification marks
VDE, EAC
- Type
32005-500
- Twisted pair cabling (part 1)
No (0)
- Twisted pair cabling (yes/no)
No (0)
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3038924 HELU 32005-500 Earth cable NYY-J 1 G 25 mm² Green-yellow 500 m
