HELU 33201-100 Data transfer cable 8 x 0.6 mm² Grey 100 m
EAN:
Part number:
Item no:
Product type
Data transfer cable
No. of leads
8 x
Cross section (each core)
0.6 mm²
Cable features
Shielded
Flame-retardant
Cross section
8 x 0.6 mm²
Datasheet (PDF)
Technical specifications
- Weight 80 kg/km
- Product type
Data transfer cable
- No. of leads
8 x
- Cross section (each core)
0.6 mm²
- Cross section
8 x 0.6 mm²
- Cable features
Shielded
Flame-retardant
- Outside Ø
7.5 mm
- Factory colour
Grey
- Content
100 m
- Bend radius (no. of ODs for fixed installation)
10
- Bend radius (no. of ODs for flexible installation)
0
- Sold per metre
No
- Shielded
Yes
- Manufacturer part #
33201-100
- Insulation material
PVC
- Wire ID code
Core identification according to DIN VDE 0815, color with ring marking
- Insulation
PE
- Core layout
Cu conductor blank, single-wired
- RoHS-compliant
Yes
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (flexible installation)
70 °C
- Min. temperature range (fixed installation)
-40 °C
- Max. temperature range (fixed installation)
70 °C
- Max. length sold by the metre
100 m
- Type
J-2Y(St)Y 4x2x0,6 GR
Documents & Downloads
Datasheet
Datasheet 2826096 HELU 33201-100 Data transfer cable 8 x 0.6 mm² Grey 100 m
User & Safety Instructions
User & Safety Instructions 2826096 HELU 33201-100 Data transfer cable 8 x 0.6 mm² Grey 100 m
Description
As a connection and connection line in dry and damp rooms for permanent routing in, under and on plaster in data transfer technology. For transmission of analogue and digital signals up to 16 Mbit/s. High crosstalk attenuation values. Suitable as a connection cable for peripheral devices, data processing systems, for screens, printers, cash systems and ISDN extension systems. These cables with (St) shielding are suitable for interference-free data and signal transmission for measurement, control and regulation systems. Installation cables are not approved for heavy current installations or for ground installation.
This text is machine translated.
