HELU 43533-500 Data transfer cable 8 x 0.75 mm² Grey 500 m
EAN:
Part number:
Item no:
Product type
Data transfer cable
No. of leads
8 x
Cross section (each core)
0.75 mm²
Cable features
Shielded
Flame-retardant
Cross section
8 x 0.75 mm²
Datasheet (PDF)
Technical specifications
- Weight 240 kg/km
- Product type
Data transfer cable
- No. of leads
8 x
- Cross section (each core)
0.75 mm²
- Cross section
8 x 0.75 mm²
- Cable features
Shielded
Flame-retardant
- Outside Ø
12.9 mm
- Factory colour
Grey
- Content
500 m
- Bend radius (no. of ODs for fixed installation)
5
- Bend radius (no. of ODs for flexible installation)
10
- Shielded
Yes
- Manufacturer part #
43533-500
- Insulation material
PVC
- Wire ID code
Core identification according to DIN 47100 (paired stranded), colored
- Insulation
PE
- Core layout
Cu-strand blank, fine-wired according to DIN VDE 0295 Class 5 / IEC 60228 Cl. 5
- RoHS-compliant
Yes
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (flexible installation)
80 °C
- Min. temperature range (fixed installation)
-20 °C
- Max. temperature range (fixed installation)
80 °C
- Certification marks
EAC
- Max. length sold by the metre
500 m
- Type
EDV-PiMF-CY 4x2x0,75 GR
Documents & Downloads
Datasheet
Datasheet 2826476 HELU 43533-500 Data transfer cable 8 x 0.75 mm² Grey 500 m
User & Safety Instructions
User & Safety Instructions 2826476 HELU 43533-500 Data transfer cable 8 x 0.75 mm² Grey 500 m
Description
As data cable with overall pair shielding and low capacities for installed terminals of medical and data technology. Further applications in tool and machine engineering, rolling and iron mills, traffic and process engineering. EMC = electromagnetic compatibility; to optimize the EMC properties, we recommend that copper braid contacts are made on both sides and over a wide area.
This text is machine translated.
