HELU 52523-100 Data transfer cable 2 x 0.5 mm² Grey 100 m
EAN:
Part number:
Item no:
Product type
Data transfer cable
No. of leads
2 x
Cross section (each core)
0.5 mm²
Cable features
Shielded
Oil-resistant
Cross section
2 x 0.5 mm²
Datasheet (PDF)
Technical specifications
- Weight 38 kg/km
- Product type
Data transfer cable
- No. of leads
2 x
- Cross section (each core)
0.5 mm²
- Cross section
2 x 0.5 mm²
- Cable features
Shielded
Oil-resistant
- Outside Ø
5.3 mm
- Factory colour
Grey
- Content
100 m
- Bend radius (no. of ODs for fixed installation)
5
- Bend radius (no. of ODs for flexible installation)
10
- Sold per metre
No
- Shielded
Yes
- Manufacturer part #
52523-100
- Insulation material
Polyurethane
- Wire ID code
Core identification according to DIN 47100, color
- Insulation
PVC
- Core layout
Cu-strand blank, 0.5 mm2: Fine strand according to DIN VDE 0295 Class 5 / IEC 60228 Cl. 5
- RoHS-compliant
Yes
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (flexible installation)
80 °C
- Min. temperature range (fixed installation)
-40 °C
- Max. temperature range (fixed installation)
80 °C
- Certification marks
EAC
- Max. length sold by the metre
100 m
- Type
DATAPUR-C 2x0,50 GR
Documents & Downloads
Datasheet
Datasheet 2826076 HELU 52523-100 Data transfer cable 2 x 0.5 mm² Grey 100 m
User & Safety Instructions
User & Safety Instructions 2826076 HELU 52523-100 Data transfer cable 2 x 0.5 mm² Grey 100 m
Description
Because of its specific structure, this cable is excellently suited for use in IT systems as well as computing systems, office machines, signal and control systems. DATAPUR-C® also proves its performance in the acoustic field in telecommunication systems, call and intercom systems, but also in weighing technology as well as in measuring and control technology. Extremely robust cable for high mechanical demands for use in dry, damp and wet rooms as well as outdoors. EMC = electromagnetic compatibility; to optimize the EMC properties, we recommend that copper braid contacts are made on both sides and over a wide area.
