HELU Industrial LED indicator light HELULIGHT® SOLID40-RGBW 365 RGBW 14.1 W 100 ° (L x W x H) 415 x 40 x 42 mm 1 pc(s)
EAN:
Part number:
Item no:
Product type
Industrial LED indicator light
Power
14.1 W
IP rating
IP67
Energy efficiency rating
n.rel.
Type
HELULIGHT® SOLID40-RGBW 365
Datasheet (PDF)
Technical specifications
- Colour of housing: Anodised natural
- Material cover: ESG
- Cover: Diffuse
- Variant connection: Flange, built-in connection socket
- Connection number of pins: 5
- Coding: A coded
- Looped through: No.
- Mounting: Rotatable
- Illuminated length 315 mm
- Hole spacing
- : 395 mm
- Product weight without packaging (g): 519
- Color fidelity CRI: 80
- Max. Illumination level 210
- Light current white 589
- Luminous flux, red: 87
- Green luminous flux: 215
- Luminous flux Blue: 60
- Output white 5.7 W
- Power red 3.1 W
- Power green 2.6 W
- Output blue 2.6 W
- Dimmable: External PWM
- Lamp life 60,000 h
- Surface temperature lamp: Label D.
- Product type
Industrial LED indicator light
- Type
HELULIGHT® SOLID40-RGBW 365
- LED features
dimmable
- Max. operating voltage
24 V DC
- Operating voltage
24 V DC (max)
14.1 W
- Factory colour
RGBW
- Colour temperature (max.)
5700 K
- Radiation angle
100°
- Connection
M12 plug
- Material
Aluminium
IP67
- Protection class
III
- Min. temperature
-20 °C
- Max. temperature
50 °C
- Length
415 mm
- Width
40 mm
- Height
42 mm
- Dim
(L x W x H) 415 x 40 x 42 mm
- RoHS-compliant
Yes
n.rel.
Documents & Downloads
Datasheet
Datasheet 3369438 HELU Industrial LED indicator light HELULIGHT® SOLID40-RGBW 365 RGBW 14.1 W 100 ° (L x W x H) 415 x 40 x 42 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3369438 HELU Industrial LED indicator light HELULIGHT® SOLID40-RGBW 365 RGBW 14.1 W 100 ° (L x W x H) 415 x 40 x 42 mm 1 pc(s)
Description
Scope of delivery
- Angle
- This text is machine translated.
