HELU Ribbon cable 12 G 1.5 mm² Black 28101-500 500 m
EAN:
Part number:
Item no:
Product type
Ribbon cable
No. of leads
12 G
Cross section (each core)
1.5 mm²
Content
500 m
Cable features
ribbon
Shielded
Flame-retardant
Technical specifications
- Weight 790 kg/km
- Cable dimensions 7.9 x 61.0 mm
- Product type
Ribbon cable
- No. of leads
12 G
- Content
500 m
- Cross section (each core)
1.5 mm²
- Cable features
ribbon
Shielded
Flame-retardant
- Wire ID code
Wire identification according to DIN VDE 0293, up to 5 wires colored, from 7 wires black, with consecutive white digits printed
- Bend radius (no. of ODs for fixed installation)
15
- Bend radius (no. of ODs for flexible installation)
0
- Manufacturer part #
28101-500
- Factory colour
Black
- Insulation material
Neoprene
- Insulation
Special rubber
- Core layout
Cu-strand blank or tin-plated, fine-strand according to DIN VDE 0295 Class 6 / IEC 60228 Cl. 6
- Max. length sold by the metre
500 m
- Sold per metre
No
- Nominal voltage U0
300 V
- Certification marks
EAC
- Cross section
12 G 1.5 mm²
- RoHS-compliant
Yes
- Max. temperature range (flexible installation)
80 °C
- Min. temperature range (flexible installation)
-30 °C
- Max. temperature range (fixed installation)
80 °C
- Min. temperature range (fixed installation)
-40 °C
- Type
NEO-flach-C 12G1,5
- Nominal voltage (details)
500 V
- Shielded
Yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2825667 HELU Ribbon cable 12 G 1.5 mm² Black 28101-500 500 m
Description
Flat cables in neoprene design are primarily used as towing cables for crane systems, industrial conveyor systems and shelving control devices. Neoprene export model with UL approval on request.
