HELU Ribbon cable 4 G 2.5 mm² + 4 G 2.5 mm² Black 28008-100 100 m
EAN:
Part number:
Item no:
Product type
Ribbon cable
No. of leads
4 G
Cross section (each core)
2.5 mm²
Content
100 m
Cable features
ribbon
Unshielded
Flame-retardant
Datasheet (PDF)
Technical specifications
- Weight 316 kg/km
- Cable dimensions 7.2 x 19.6 mm
- Product type
Ribbon cable
- No. of leads
4 G
- Content
100 m
- Cross section (each core)
2.5 mm²
- Cable features
ribbon
Unshielded
Flame-retardant
- Cross section (each core) (part 2)
2.5 mm²
- No. of leads (part 2)
4 G
- Wire ID code
Wire identification according to DIN VDE 0293, up to 5 wires colored, from 7 wires black, with consecutive white digits printed
- Bend radius (no. of ODs for fixed installation)
10
- Bend radius (no. of ODs for flexible installation)
0
- Manufacturer part #
28008-100
- Factory colour
Black
- Insulation material
Neoprene
- Insulation
Special rubber
- Core layout
Cu-strand blank or tin-plated, 1.5 - 25 mm2: Finely stranded according to DIN VDE 0295 Class 6 / IEC 60228 Cl. 635 - 120 mm²: Finely stranded according to DIN VDE 0295 Class 5 / IEC 60228 Cl. 5
- Max. length sold by the metre
100 m
- Sold per metre
No
- Nominal voltage U0
300 V
- Certification marks
EAC
- Cross section
4 G 2.5 mm² + 4 G 2.5 mm²
- RoHS-compliant
Yes
- Suited for cable carriers
Yes
- Max. temperature range (flexible installation)
80 °C
- Min. temperature range (flexible installation)
-30 °C
- Max. temperature range (fixed installation)
80 °C
- Min. temperature range (fixed installation)
-40 °C
- Type
NEO-flach 4G2,5
- Nominal voltage (details)
500 V
- Shielded
No
Documents & Downloads
Datasheet
Datasheet 2825800 HELU Ribbon cable 4 G 2.5 mm² + 4 G 2.5 mm² Black 28008-100 100 m
User & Safety Instructions
User & Safety Instructions 2825800 HELU Ribbon cable 4 G 2.5 mm² + 4 G 2.5 mm² Black 28008-100 100 m
Description
Flat cables in neoprene design are primarily used as towing cables for crane systems, industrial conveyor systems and shelving control devices. Neoprene export model with UL approval on request.
