Buy HELU Y-CY-JZ Control lead 4 G 2.5 mm² Transparent 16295-500 500 m

Close-up of a braided cable with the label: 'NEUKABEL H05RR-F 3G2.5 300/500V 2019/07 ❖D3050❖ CE', showing three coloured cores.

Image similar

Product type

Control lead

No. of leads

4 G

Cross section (each core)

2.5 mm²

Cable type

Y-CY-JZ

Outside Ø

11.50 mm

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Technical specifications

Product type: Control lead

No. of leads: 4 G

Content: 500 m

Cross section (each core): 2.5 mm²

Cable features: Flame-retardant
Flexible
Shielded
chemical-resistant
incl. graduation (metres)
Oil-resistant

Cable type: Y-CY-JZ

Outside Ø: 11.50 mm

Packaged: Yes

Wire ID code: DIN VDE 0293

Bend radius (no. of ODs for fixed installation): 4

Bend radius (no. of ODs for flexible installation): 7.5

Halogen-free: No

Manufacturer part #: 16295-500

Factory colour: Transparent

Insulation material: PVC

Insulation: PVC

Core layout: Plain Cu braid, according to DIN VDE 0295 class 5, fine strand

Material (details): PVC

Sold per metre: No

Nominal voltage: 500 V

Nominal voltage U0: 300 V

Number-coded: Yes

Test voltage: 4000 V

Cross section: 4 G 2.5 mm²

RoHS-compliant: Yes

Suited for cable carriers: No

Max. temperature range (flexible installation): +80 °C

Min. temperature range (flexible installation): -15 °C

Max. temperature range (fixed installation): +80 °C

Min. temperature range (fixed installation): -40 °C

Type: 16295-500

Variants(All information is without VAT, plus shipping costs)

No. of leads

Content

Cross section (each core)

Outside Ø

Cable features

HELU Y-CY-JZ Control lead 3 G 0.75 mm² Transparent 16224 100 m

Item no:1972593

3 G

100 m

0.75 mm²

8 mm

Flame-retardantFlexibleShieldedchemical-resistantincl. graduation (metres)Oil-resistant

HELU Y-CY-JZ Control lead 3 G 0.50 mm² Transparent 16201 100 m

Item no:1972670

3 G

100 m

0.50 mm²

7.30 mm

Flame-retardantFlexibleShieldedchemical-resistantincl. graduation (metres)Oil-resistant

HELU Y-CY-JZ Control lead 3 G 1.5 mm² Transparent 16272 100 m

Item no:1972734

3 G

100 m

1.5 mm²

9.20 mm

Flame-retardantFlexibleShieldedchemical-resistantincl. graduation (metres)Oil-resistant

HELU Y-CY-JZ Control lead 3 G 2.5 mm² Transparent 16294 100 m

Item no:1972740

3 G

100 m

2.5 mm²

10.80 mm

Flame-retardantFlexibleShieldedchemical-resistantincl. graduation (metres)Oil-resistant

HELU Y-CY-JZ Control lead 3 G 1 mm² Transparent 16249 100 m

Item no:1972755

3 G

100 m

1 mm²

8.30 mm

Flame-retardantFlexibleShieldedchemical-resistantincl. graduation (metres)Oil-resistant

HELU Y-CY-JZ Control lead 3 G 4 mm² Transparent 16300 100 m

Item no:1972821

3 G

100 m

4 mm²

12.50 mm

Flame-retardantFlexibleShieldedchemical-resistantincl. graduation (metres)Oil-resistant

HELU Y-CY-JZ Control lead 4 G 0.50 mm² Transparent 16202 100 m

Item no:1972827

4 G

100 m

0.50 mm²

7.90 mm

Flame-retardantFlexibleShieldedchemical-resistantincl. graduation (metres)Oil-resistant

HELU Y-CY-JZ Control lead 3 G 4 mm² Transparent 16300-1000 1000 m

Item no:3038770

3 G

1000 m

4 mm²

12.50 mm

Flame-retardantFlexibleShieldedchemical-resistantincl. graduation (metres)Oil-resistant

HELU Y-CY-JZ Control lead 3 G 2.5 mm² Transparent 16294-1000 1000 m

Item no:3039072

3 G

1000 m

2.5 mm²

10.80 mm

Flame-retardantFlexibleShieldedchemical-resistantincl. graduation (metres)Oil-resistant

HELU Y-CY-JZ Control lead 3 G 1.5 mm² Transparent 16272-1000 1000 m

Item no:3039213

3 G

1000 m

1.5 mm²

9.20 mm

Flame-retardantFlexibleShieldedchemical-resistantincl. graduation (metres)Oil-resistant

Documents & Downloads

Datasheet

Datasheet 3041219 HELU Y-CY-JZ Control lead 4 G 2.5 mm² Transparent 16295-500 500 m

User & Safety Instructions

User & Safety Instructions 3041219 HELU Y-CY-JZ Control lead 4 G 2.5 mm² Transparent 16295-500 500 m
