Hobbywing QuicRun 10BL120 G2 120A Model car brushless speed control Load (Amp max.): 760 A
EAN:
Part number:
Item no:
Total (€ 48.73 / piece)
€ 48.73
plus VAT.
14-day return policy included
Highlights & Details
Hobbywing QuickRun 10BL120 G2 120A Sensed Controller 2-3s
- More setting options than the previous model (among others Turbo Delay, Turbo Timing and Boost Timing)
- Improved BEC output with switch instead of linear mode
- Motor rotation direction can be selected freely (CW or CCW)
- Top performance at a low price
- Compact design, suitable for a multiplicity at chassis
- Ideal for many application areas and competitions
- Various protective functions: Overheating protection, undervoltage switch-off
Technical specifications
- Input voltage 2-3S Lipo
- Motor Limit: 2S: >=4.5T, 3650 engine, 3S: >=10.5T, 3650 engine
- Suitable vehicles: 1/10 touring car, buggy, drift
- Programming: SET button, LED programming card, LCD programming box (G2)
- Product type
Model car brushless speed control
- Dim
(L x W x H) 44 x 37 x 32 mm
- Weight
102 g
- BEC data
6V / 7.4V at 4A (Switch Mode)
- Load (max.)
760 A
- Permanent current
120 A
- Manufacturer part #
30125002
- Width
37 mm
- Height
32 mm
- Length
44 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3400166 Hobbywing QuicRun 10BL120 G2 120A Model car brushless speed control Load (Amp max.): 760 A
Description
The 2nd. Generation of the Quickrun 10BL120 regulator represents a classical, solid brushless solution for 1/10 vehicles such as touring cars, buggies and drifter. With extended BEC and a lot of additional parameters the controller is in no way inferior to its predecessor. The QuickRun series from Hobbywing offers a cost-effective alternative for all drivers, who simply want to achieve more with their setup - whether with brushless motors or not. It is aimed primarily at beginners and advanced pilots and impresses through the outstanding quality of the Hobbywing products as well as through the uncomplicated start-up.
