Holzmann Maschinen HOB260MINI_400V Jointer planer combo 63 mm
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Jointer planer combo
- Planer width: 63 mm
- Dim. table 1.04 mm
Technical specifications
- Max. Dressing Chip removal in mm 3
- Alignment stop in mm 1100 x 150
- Feed speed 5 m/min.
- Thickness planer table size in mm 400 x 260
- Max. Thickness planing Chip removal in mm 3
- Passage height in mm 160
- Number of plane blades 2
- Sound power level in dB(A) 102.1/99.1
- Sound pressure level in dB(A) 56.6/91.5
- Product type
Jointer planer combo
- Power S6
2800 W
- Rotational speed
6500 U/min
- Hose connector
100 mm
- Plane width
63 mm
- Swivel range (min)
45°
- Swivel range (max.)
90°
- Swivel range (range)
45 - 90 °
- Operating voltage
400 V
- Table length
1.04 mm
- Table width
26 mm
- Desk height
86 cm
- Weight
72 kg
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3475884 Holzmann Maschinen HOB260MINI_400V Jointer planer combo 63 mm
User & Safety Instructions
User & Safety Instructions 3475884 Holzmann Maschinen HOB260MINI_400V Jointer planer combo 63 mm
Description
The HOB260MINI compact panel thickness machine with driving device, reversible plane blade should be available in its wood workshop. With a width of 260 mm and a thickness planer blade, great projects can be implemented
This text is machine translated.
This text is machine translated.
Scope of delivery
- 2 reversible plane irons (260 x 18.6 x 1.2 mm)
